MASWSS0148 Datasheet, Switch, Tyco Electronics

MASWSS0148 Features

• Switch
• High Isolation: 55 dB @ 2 GHz Insertion Loss: 1.6 dB @ 2 GHz Terminated RF Input in Isolation S

PDF File Details

Part number:

MASWSS0148

Manufacturer:

Tyco Electronics

File Size:

243.89kb

Download:

📄 Datasheet

Description:

Gaas spst high isolation terminated switch. M/A-COM’s MASWSS0148 is a GaAs monolithic single pole single throw (SPST) terminated switch in a lead-free 3 mm 12-lead PQFN plastic

MASWSS0148 Application

• Applications include PCS and GSM LO switching, switch matrices and switched filter banks in systems such as radio and cellular equipment. The MASWSS
