MASWSS0169 Datasheet, Switch, Tyco Electronics

MASWSS0169 Features

• Switch
• Low Power Consumption: < 20 µA @ +3 V High Isolation: 50 dB Typical @ 2 GHz Low Insertion Loss:

PDF File Details

Part number:

MASWSS0169

Manufacturer:

Tyco Electronics

File Size:

206.07kb

Download:

📄 Datasheet

Description:

Gaas high isolation switch. M/A-COM’s MASWSS0169 is a GaAs MMIC SPDT switch in a lead-free MSOP-10 surface mount plastic package. This part is ideal for high iso

MASWSS0169 Application

• Applications include synthesizer switching, transmit/ receive switching, switch matrices and filter banks in systems such as radio and cellular equi
