Description

The UM8329/B is an MOS integrated circuit designed to complement either the 179X or 8272A (765A) type of floppy disk controller chip.

Features

Digital date separator Performs complete data separation function for floppy disk drives Separates FM and MFM encoded data No critical adjustments necessary 5%" and 8" compatible.
Variable write precompensation.
Internal crystal osci lIator circu it.
Track-selectable write precompensation.
Retriggerable head-load timer.
Compatible with the FDC 179X, 8272A, and other standard floppy disk controllers.
SAN-III MOS N-.
