BCM380P475T1K2A30 Fixed Ratio DC-DC Converter

The VI Chip® Bus Converter (BCM®) is a high efficiency Sine Amplitude Converter™ (SAC™), operating from a 260 to 410 VDC primary bus to deliver an isolated, ratiometric output from 32.5 to 51.3 VDC. The BCM380x475y1K2A3z offers low noise, fast transient response, and industry leading efficiency and .

BCM380P475T1K2A30 Features

* Up to 1200 W continuous output power

* 1876 W/in3 power density

* 97.9% peak efficiency

* 4,242 Vdc isolation

* Parallel operation for multi-kW arrays

* OV, OC, UV, short circuit and thermal protection

* 6123 through-hole ChiP package n 2.494

BCM380P475T1K2A30-Vicor.pdf

BCM380P475T1K2A30 Datasheet Preview — Preview of BCM380P475T1K2A30 PDF

BCM380P475T1K2A30 Datasheet Preview Page 2

BCM380P475T1K2A30 Datasheet Preview Page 3

Datasheet Details

Part number:

BCM380P475T1K2A30

Manufacturer:

Vicor

File Size:

1.24 MB

Description:

Fixed ratio dc-dc converter.
