SI2305ADS
FEATURES
ID (A)
- 4.1
- 3.4
- 2.0 7.8 n C Qg (Typ.)
PRODUCT SUMMARY
VDS (V) RDS(on) (Ω) 0.040 at VGS =
- 4.5 V -8 0.060 at VGS =
- 2.5 V 0.088 at VGS =
- 1.8 V
- Halogen-free Option Available
- Trench FET® Power MOSFET
- 100 % Rg Tested
Ro HS
PLIANT
APPLICATIONS
- Load Switch
- DC/DC Converter
TO-236 (SOT-23)
S 3 S 2 D G
Top View Si2305ADS (A5)-
- Marking Code Ordering Information: Si2305ADS-T1-E3 (Lead (Pb)-free) Si2305ADS-T1-GE3 (Lead (Pb)-free and Halogen-free) D P-Channel MOSFET
ABSOLUTE MAXIMUM RATINGS TA = 25 °C, unless otherwise noted
Parameter Drain-Source Voltage Gate-Source Voltage TC = 25 °C TC = 70 °C TA = 25 °C TA = 70 °C TC = 25 °C TA = 25 °C TC = 25 °C TC = 70 °C TA = 25 °C TA = 70 °C Symbol VDS VGS Limit -8 ±8
- 5.4
- 4.3
- 4.1a, b
- 3.3a, b
- 10
- 1.4
- 0.8a, b 1.7 1.1 0.96a, b 0.62a, b
- 50 to 150 260 Unit V
Continuous Drain Current (TJ = 150 °C)
Pulsed Drain Current Continuous Source-Drain Diode Current
IDM IS
Maximum Power...
