TCUT1600X01 Datasheet, Sensor, Vishay

✔ TCUT1600X01 Features

Package type: surface-mount
Detector type: phototransistor
Dimensions (L x W x H in mm): 5.5 x 4 x 5.7
AEC-Q101 qualified
Gap (in mm): 3
Aperture (in mm): 0.3

✔ TCUT1600X01 Application

Automotive optical sensors
Accurate position sensor for encoder
Sensor for motion, speed, and directio

PDF File Details

Vishay manufacturer logo

Part number:

TCUT1600X01

Manufacturer:

Vishay ↗

File Size:

223.61 KB

Download:

📄 Datasheet

Description:

Tall dome dual channel transmissive optical sensor. The TCUT1600X01 is a compact transmissive sensor that includes an infrared emitter and two phototransistor detectors, located face-to

📥 Download PDF (223.61 KB)
