DB101S Datasheet - WEJ

DB101S SINGLE-PHASE BRIDGE RECTIFIER

RoHS DF005S-DF10S SINGLE-PHASE BRIDGE RECTIFIER VOLTAGE RANGE 50 to 1000 Volts CURRENT 1.0 Amperes F E AT U R E S Glass passivated chip junctions Ideal for surface mounted applications DLow leakage High forward surge current capability. THigh temperature soldering guaranteed: 260oC/10 seconds at terminals. .,LMECHANICAL DATA Case:Transfer molded plastic OEpoxy:UL94V-0 rate flame retardant Lead:Plated axial lead ,solderable per MIL-STD-202E Cmethod 208C Polarity:Molded on body Mounting pos.

DB101S-WEJ.pdf

DB101S Datasheet Preview — Preview of DB101S PDF

Datasheet Details

Part number:

DB101S

Manufacturer:

WEJ

File Size:

231.45 KB

Description:

Single-phase bridge rectifier.
