AG303 Datasheet, Block, WJ Communications

AG303 Features

• Block Product Description Functional Diagram
• DC - 5000MHz
• +13 dBm P1dB at 900MHz
• +27 dBm OIP3 at 900MHz
• 20.5 dB Gain at 900MHz
• Single Volt

PDF File Details

Part number:

AG303

Manufacturer:

WJ Communications

File Size:

215.69kb

Download:

📄 Datasheet

Description:

Ingap hbt gain block. Functional Diagram

DC - 5000MHz

+13 dBm P1dB at 900MHz

+27 dBm OIP3 at 900MHz

20.5 dB Gain

AG303 Application

• Applications within the DC to 5 GHz frequency range such as CATV and fixed wireless. RF in GND AG33 RF OUT GND AG303-86 GND RF OUT GND GND
