Datasheet Details

Part number	XNS50660AB
Manufacturer	Xiner
File Size	1.09 MB
Description	IPM
Datasheet	XNS50660AB-Xiner.pdf

XNS50660AB Product details

Description

XNS50660AB/ABSTrench FS-IGBT，（）。 XNS50660AB/ABS is an Advanced IPM Based on Trench FS-IGBT Technology as a Compact Inverter Solution for Small Power Motor Drive Applications Such as Fans and Pumps. XNS50660AB/ABS6IGBTFRD，3HVIC3，。 XNS50660AB/ABS Contains Six IGBTs and FRDs, Three Half-Bridge Gate Drive HVICs with Temperature Sensing, and Three Bootstrap Diodes in a Compact Package Fully Isolated and Optimized for Thermal Performance. XNS50660AB/ABS（EMI）。 XNS50660AB/ABS

Features

-Phase Inverter Including HVICs.
Three Separate Open-Source Pins from Low Side IGBTs for Three Leg Current Sensing.
HVIC for Gate Driving and Undervoltage Protection.
Active-High Interface, Can Work With 3.3 V / 5 V Logic.
Optimized for Low Electromagnetic Interference.
Isolation Voltage Rating of 1500 Vrms for 1 min.
Temperature Sense Unit in HVIC.
Embedded Bootstrap Diode in the Package.
ROHS Compliant.
