XP9412GI N-CHANNEL ENHANCEMENT MODE POWER MOSFET

📥 Download Datasheet  Datasheet Preview Page 1

Description

XP9412GI Halogen-Free Product N-CHANNEL ENHANCEMENT MODE POWER MOSFET ▼ Fast Switching Performance D ▼ Simple Drive Requirement ▼ Full Isolation P.
XP9412 series are innovated design and silicon process technology to achieve the lowest possible on-resistance and fast switching performance.

📥 Download Datasheet

Preview of XP9412GI PDF
datasheet Preview Page 2 datasheet Preview Page 3

Datasheet Specifications

Part number
XP9412GI
Manufacturer
YAGEO
File Size
212.38 KB
Datasheet
XP9412GI-YAGEO.pdf
Description
N-CHANNEL ENHANCEMENT MODE POWER MOSFET

Applications

* The TO-220CFM package is widely preferred for all commercial-industrial through hole applications. The mold compound provides a high isolation voltage capability and low thermal resistance between the tab and the external heat-sink. BVDSS RDS(ON) ID 30V 6mΩ 68A GD S TO-220CFM(I) Absolute Maxim
