AS1112

16-Channel LED Driver

AS1112 General Description

The AS1112 is a 16-channel, constant current-sink LED driver. Each of the 16 channels can be individually adjusted by 4096-step greyscale PWM brightness control and 64-step constant-current sink (dot correction). The dot correction circuitry adjusts the brightness variations between the AS1112 cha.

AS1112 Datasheet (1.12 MB)

Preview of AS1112 PDF

Datasheet Details

Part number:

AS1112

Manufacturer:

austriamicrosystems AG

File Size:

1.12 MB

Description:

16-channel led driver.
