CD40106BF Datasheet, Inverters, Texas Instruments

CD40106BF Features

• Inverters
• 1 Schmitt-Trigger Inputs
• Hysteresis Voltage (Typical):
    – 0.9 V at VDD = 5 V
    – 2.3 V at VDD = 10 V
    – 3.5 V at VDD = 15

PDF File Details

Part number:

CD40106BF

Manufacturer:

Texas Instruments ↗

File Size:

1.38MB

Download:

📄 Datasheet

Description:

Cmos hex schmitt-trigger inverters. The CD40106B device consists of six Schmitt-Trigger inputs. Each circuit functions as an inverter with Schmitt-Trigger input. The tri

CD40106BF Application

• Applications
• Wave and Pulse Shapers
• High-Noise-Environment Systems
• Monostable Multivibrators
• Astable Multivi
