CD74HC40105 Datasheet, Register, Texas Instruments

CD74HC40105 Features

• Register Description
• Independent Asynchronous Inputs and Outputs
• Expandable in Either Direction
• Reset Capability
• Status Indicators on Inputs and Outputs

PDF File Details

Part number:

CD74HC40105

Manufacturer:

Texas Instruments ↗

File Size:

899.36kb

Download:

📄 Datasheet

Description:

4-bit x 16-word fifo register.

Independent Asynchronous Inputs and Outputs

Expandable in Either Direction

Reset Capability

CD74HC40105 Application

• Applications
• Bit-Rate Smoothing
• CPU/Terminal Buffering
• Data Communications
• Peripheral Buffering
• Li
