ISO7763, ISO7760 Datasheet - Texas Instruments

ISO7763 reinforced six-channel digital isolator

The ISO776x devices are high-performance, sixchannel digital isolators with 5000-VRMS (DW package) and 3000-VRMS (DBQ package) isolation ratings per UL 1577. This family of devices is also certified according to VDE, CSA, TUV and CQC. The ISO776x family of devices provides highelectromagnetic immuni.

ISO7763 Features

* 100 Mbps data rate

* Robust isolation barrier:

* >100-Year projected lifetime

* Up to 5000 VRMS isolation rating

* Up to 12.8 kV surge capability

* ±100 kV/μs Typical CMTI

* Wide supply range: 2.25 V to 5.5 V

* 2.25-V to 5.5-V Level t

ISO7760-etcTI.pdf

This datasheet PDF includes multiple part numbers: ISO7763, ISO7760. Please refer to the document for exact specifications by model.
ISO7763 Datasheet Preview Page 2 ISO7763 Datasheet Preview Page 3
