PTH03000W Datasheet, module equivalent, Texas Instruments

PTH03000W Features

• Module
• Up to 6-A Output Current
• 3.3 V Input Voltage
• Wide-Output Voltage Adjust (0.9 V to 2.5 V)
• Efficiencies up to 95 %
• 115 W/in³ Power Densit

PDF File Details

Part number:

PTH03000W

Manufacturer:

Texas Instruments (https://www.ti.com/)

File Size:

373.58kb

Download:

📄 Datasheet

Description:

3.3-v input non-isolated wide-output adjust power module. The PTH03000 series of non-isolated power modules are small in size and high on performance. Using double-sided surface mount constru

PTH03000W Application

• Applications where space, performance and cost are important design constraints. The series operates from an input voltage of 3.3 V to provide step-
