LF221S Datasheet, Converters, micropowerdirect

LF221S Features

• Converters
• 2W Output Power
• Ultra-Miniature SMT Case
• 1,000 VDC Isolation
• 5V, 12 & 24V Inputs
• -40ºC to +85ºC Operation
• 6 Standard Models

PDF File Details

Part number:

LF221S

Manufacturer:

micropowerdirect

File Size:

294.05kb

Download:

📄 Datasheet

Description:

2w single output smt dc/dc converters. -Vin +Vin No Pin -Vout +Vout No Pin No Pin NA NA = Not for electrical connection Notes:

All dimensions are typical in inc

LF221S Application

• Applications the use of 1.5 µF capacitors will reduce the output ripple. 3. Operation at no-load will not damage these units. However, they may not
