74HC2G00DC Datasheet, Gate, nexperia

74HC2G00DC Features

• Gate
• Wide supply voltage range from 2.0 V to 6.0 V
• Input levels:
• For 74HC2G00: CMOS level
• For 74HCT2G00: TTL level
• Symmetrical output impeda

PDF File Details

Part number:

74HC2G00DC

Manufacturer:

nexperia ↗

File Size:

197.23kb

Download:

📄 Datasheet

Description:

Dual 2-input nand gate. The 74HC2G00; 74HCT2G00 is a dual 2-input NAND gate. Inputs include clamp diodes. This enables the use of current limiting resistors
