74LVC1G125-Q100 Datasheet, Driver, nexperia

74LVC1G125-Q100 Features

• Driver
• Automotive product qualification in accordance with AEC-Q100 (Grade 1)
• Specified from -40 °C to +85 °C and from -40 °C to +125 °C
• Wide supply voltage range

PDF File Details

Part number:

74LVC1G125-Q100

Manufacturer:

nexperia ↗

File Size:

230.89kb

Download:

📄 Datasheet

Description:

Bus buffer/line driver. The 74LVC1G125-Q100 is a single buffer/line driver with 3-state output. Inputs can be driven from either 3.3 V or 5 V devices. This f

74LVC1G125-Q100 Application

• Applications using IOFF. The IOFF circuitry disables the output, preventing the potentially damaging backflow current through the device when it is
