BAV70W-Q - High-speed switching double diode

Product Overview

nexperia

📥 Download Datasheet

BAV70W-Q High-speed switching double diode by nexperia - Datasheet Preview — Datasheet preview – BAV70W-Q

Datasheet Details

Part number	BAV70W-Q
Manufacturer	nexperia
File Size	200.28 KB
Description	High-speed switching double diode
Datasheet	BAV70W-Q Datasheet
Additional preview pages of the BAV70W-Q datasheet.

Product details

Description

High-speed switching double diode, encapsulated in a very small SOT323 (SC-70) SurfaceMounted Device (SMD) plastic package.

Features

High switching speed: trr ≤ 4 ns.
Low capacitance: Cd ≤ 1.5 pF.
Low leakage current.
Reverse voltage: VR ≤ 100 V.
Very small SMD plastic package.
Qualified according to AEC-Q101 and recommended for use in automotive.
