Datasheet Summary
Features
- Epitaxial Planar Die Construction
- Ideal for Low-Power Amplification and Switching
- plementary NPN Type: MMBT2222A
- Totally Lead-Free & Fully RoHS pliant (Notes 1 & 2)
- Halogen and Antimony Free. “Green” Device (Note 3)
- An automotive-pliant part is available under separate datasheet (MMBT2907AQ)
60V PNP SMALL-SIGNAL TRANSISTOR IN SOT23
Mechanical Data
- Package: SOT23
- Package Material: Molded Plastic, “Green” pound;
UL Flammability Classification Rating 94V-0
- Moisture Sensitivity: Level 1 per J-STD-020
- Terminals: Finish
- Matte Tin Plated Leads, Solderable per
MIL-STD-202, Method 208
- Weight: 0.008 grams (Approximate)
SOT23
