MJD350 - HIGH VOLTAGE PNP TRANSISTOR

Key Features

  • Epitaxial Planar Die Construction.
  • High Collector-EmitterVoltage.
  • Ideally Suited for Automated Assembly Processes.
  • Ideal for Power Switching or Amplification.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MJD350 PNP Epitaxial Silicon Transistor Kexin
MJD350 Silicon PNP transistor BLUE ROCKET ELECTRONICS
MJD350 SMD Transistor TAITRON
MJD350 High Voltage Power Transistor Fairchild
MJD350 COMPLEMENTARY SILICON POWER TRANSISTORS ST Microelectronics

Other Datasheets by Diodes Incorporated

Part Number Description
MJD31C NPN Transistor
MJD31CQ 100V NPN HIGH VOLTAGE TRANSISTOR
MJD31CUQ 100V NPN HIGH VOLTAGE TRANSISTOR
MJD32C PNP Transistor
MJD32CQ PNP Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
NEW PRODUCT MJD350 HIGH VOLTAGE PNP SURFACE MOUNT TRANSISTOR Features • Epitaxial Planar Die Construction • High Collector-EmitterVoltage • Ideally Suited for Automated Assembly Processes • Ideal for Power Switching or Amplification Applications • Lead Free By Design/RoHS Compliant (Note 1) • "Green" Device (Note 2) Mechanical Data • Case: DPAK • Case Material: Molded Plastic, "Green" Molding Compound. UL Flammability Classification Rating 94V-0 • Moisture Sensitivity: Level 1 per J-STD-020D • Terminals: Finish — Matte Tin annealed over Copper Leadframe (Lead Free Plating). Solderable per MIL-STD-202, Method 208 • Marking Information: See Page 3 • Ordering Information: See Page 3 • Weight: 0.
