BAV99-Q1 Datasheet | Formosa MS

SMD Switching Diode Formosa MS BAL99-Q1/BAV99-Q1/BAW56-Q1/BAV70-Q1 100~215mA Surface Mount Switching Diode 70V~75V Features - Fast speed switching - For general purpose switching application - High conductance - Silicon epitaxial planar chip - Lead-free parts meet RoHS requirements - Qualified to AEC-Q101 standards for high reliability - Suffix "-H" indicates Halogen-free part, ex.BAL99-Q1-H Package outline SOT-23 0.042 (1.05) 0.034 (0.85) 0.020 (0.50) 0.012 (0.30) 0.120 (3.04) 0.110 (2.80) .084(2.10) .068(1.70) Mechanical data - Epoxy:UL94-V0 rated flame retardant - Case : Molded plastic, SOT-23 - Terminals : Solder plated, solderable per MIL-STD-750, Method 2026 - Mounting...
