BAV99T
BAV99T is SMD Small Signal Switching Diode manufactured by Formosa MS.
- Part of the BAV70T comparator family.
- Part of the BAV70T comparator family.
SMD Small Signal Switching Diode
Formosa MS
BAS16T/BAV70T/BAW56T/BAV99T
150mW Surface Mount Small Signal Switching Diode- 85V
Features
- Fast speed switching.
- For general purpose switching application.
- High conductance.
- Silicon epitaxial planar chip.
- Lead-free parts meet RoHS requirments.
- Suffix "-H" indicates Halogen free parts, ex. BAS16T-H.
Mechanical data
- Epoxy:UL94-V0 rated flame retardant
- Case : Molded plastic, SOT-523
- Terminals : Solder plated, solderable per
MIL-STD-750, Method 2026
- Mounting Position : Any
- Weight : Approximated 0.003 gram
Package outline
SOT-523
0.020 (0.50)Max
0.014 (0.35) 0.006 (0.15)
0.067 (1.70) 0.060 (1.50) .044(1.10)...
