FMMT619-3L Datasheet NPN Silicon Planar Medium Power Transistor

Manufacturer: Galaxy Microelectronics

Overview: NPN Silicon Planar Medium Power Transistor FMMT619 FMMT619-3L.

This datasheet includes multiple variants, all published together in a single manufacturer document.

Key Features

  • BVCEO > 50V.
  • IC = 2A Continuous Collector Current.
  • 625mW power dissipation.
  • Low Saturation Voltage VCE(sat) < 200mV @ 1A.
  • RCE(SAT) = 68mΩ for a low equivalent on-resistance.
  • HFE characterised up to 6A for high current gain hold-up.
  • Complementary PNP type: FMMT720, FMMT720-3L FMMT619 SOT-23 Mechanical Data.
  • Case: SOT-23,SOT-23-3L.
  • Molding compound, UL flammability classification rating 94V-0.
  • Terminals: Matte tin plated leads, solderable p.
