FS01
FS01 is Pressure Sensors manufactured by Honeywell.
FEATURES
- 0 to 1.5 pounds and 0 to
3.0 pound ranges
- High-level output range
- Temperature pensated
- Calibrated zero and span
- Small size
- Low noise
TYPICAL APPLICATIONS
- Medical infusion pumps
- Ambulatory noninvasive pump pressure
- Occulsion detection
- Kidney dialysis machines
- Load and pression sensing
- Variable tensions control
The FS01/FS03 sensors are special low cost, peizoresistive-based force sensors. These high-level voltage output, calibrated, and temperature pensated sensors give an accurate and stable output over a 5 °C to 50 °C [41 °F to 122 °F] temperature range. They offer simple operation from a single 5.0 Vdc supply. Operation from any DC supply voltage, up to 12.0 Vdc, is acceptable.
The FS01/FS03 sensors feature an integrated circuit sensor element and laser trimmed think film ceramic in a small plastic housing. Their extremely small size enables the use of multiple sensors in limited available space. This package also provides excellent corrosion resistance and isolation to external package stress.
WARNING
PERSONAL INJURY DO NOT USE these products as safety or emergency stop devices or in any other application where failure of the product could result in personal injury. Failure to ply with these instructions could result in death or serious injury.
WARNING
MISUSE OF DOCUMENTATION
- The information presented in this product sheet is for reference only. Do not use this document as a product installation guide.
- plete installation, operation, and maintenance information is provided in the instructions supplied with each product. Failure to ply with these instructions could result in death or serious injury.
Sensing and Control
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-.stevenengineering.
Pressure Sensors FS01/FS03 Force Sensors
PRESSURE SENSOR SPECIFICATIONS
Max. Ratings
Supply voltage, Vs
12.0 Vdc
Maximum over...
