BD678 - PNP Transistor

Product Overview

📥 Download Datasheet

Datasheet preview – BD678

Datasheet Details

Part number BD678
Manufacturer INCHANGE
File Size 185.27 KB
Description PNP Transistor
Datasheet download datasheet BD678 Datasheet
Additional preview pages of the BD678 datasheet.

Product details

Description

Collector Emitter Breakdown Voltage : V(BR)CEO = -60 DC Current Gain : hFE = 750(Min) @ IC= -1.5 A Complement to Type BD677 Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS Designed for use as output devices in complementary general-purpose amplifier applications.ABSOLUTE MAXIMUM RATINGS(Ta=25℃) SYMBOL PARAMETER VALUE UNIT VCBO Collector-Base Voltage -60 V VCEO Collector-Emitter Voltage
