2SC3441
2SC3441 is SILICON NPN EPITAXIAL TYPE TRANSISTOR manufactured by Isahaya Electronics Corporation.
DESCRIPTION
OUTLINE DRAWING
2SA3441 is a super mini silicon NPN epitaxial type transistor
2.8 designed with high collector current, high voltage.
0.65 1.5 0.65 plementary with 2SA1366.
Unit：ｍｍ
2.8 1.90 0.95 0.95
FEATURE
- Excellent linearity of DC forward current gain.
- High VCEO VCEO=50V
- Super mini package for easy mounting.
- High collector current ICM=600m A
- High gain band width product f T=150MHz typ
①
②
③
1.1 0.8 0～0.1 0.13
APPLICATION For switching, small type motor application
MAXIMUM RATINGS（Ta=25℃）
TERMINAL CONNECTOR
①：BASE
②：EMITTER
.
③：COLLECTOR
JEITA：SC-59 JEDEC：Similar to TO-236
Parameter
Symbol
Ratings
Unit
Collector to Base voltage Emitter to Base voltage Collector to Emitter voltage Collector current Peak Collector current Collector dissipation Junction temperature Storage temperature
VCBO VEBO VCEO
IC ICM PC Tj Tstg
400 m A
600 m A
200 m W
＋150
℃
-55～＋150...
