BAS21H
BAS21H is Switching Diode manufactured by Kexin Semiconductor.
- Part of the BAS20H comparator family.
- Part of the BAS20H comparator family.
Features
- Fast Switching Speed
- Surface Mount Package Ideally Suited for Automatic Insertion
- High Conductance
- For General Purpose Switching Applications
SOD-323
1.7 +0.1 -0.1
2.6 +0.1 -0.1
+ 0.3 0.05
- 0.05
+0.1 1.3 -0.1
Diodes
Unit: mm
0.85 +0.05 -0.05
1.0max
+ 0.1 0.05
- 0.02
- Absolute Maximum Ratings Ta = 25℃
Parameter
Symbol BAS19H
BAS20H
Non-Repetitive Peak Reverse Voltage
VRRM
Working Peak Reverse Voltage DC Blocking Voltage
VRWM
RMS Reverse Voltage
VR(RMS)
Average Rectified Output Current (1)
Forward Continuous Current...
