KI10N06DY - N-Channel MOSFET

Key Features

  • s.
  • VDS (V) = 60V.
  • RDS(ON) ＜ 18mΩ (VGS = 10V), ID = 9.2 A.
  • RDS(ON) ＜ 28mΩ (VGS = 4.5V), ID = 7.5 A.
  • Low Input Capacitance.
  • Fast Switching Speed D +0.04 0.21 -0.02 SOP-8 G S TraMnOsiSsFtoErsT 1.50 0.15 1 Source 2 Source 3 Source 4 Gate 5 Drain 6 Drain 7 Drain 8 Drain.
  • Absolute Maximum Ratings (TA = 25℃,unless otherwise specified. ) Drain-Source Voltage Gate-Source Voltage Parameter Continuous Drain Current (Note 2), VGS = 10V Steady State t.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer

Other Datasheets by Kexin Semiconductor

Part Number Description
KI10N03 N-Channel MOSFET
KI10P40DY P-Channel MOSFET
KI138K N-Channel MOSFET
KI1563DH Complementary 20-V (D-S) Low-Threshold MOSFET

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
SMD Type N-Channel MOSFET KI10N06DY ■ Features ● VDS (V) = 60V ● RDS(ON) ＜ 18mΩ (VGS = 10V), ID = 9.2 A ● RDS(ON) ＜ 28mΩ (VGS = 4.5V), ID = 7.5 A ● Low Input Capacitance ● Fast Switching Speed D +0.04 0.21 -0.02 SOP-8 G S TraMnOsiSsFtoErsT 1.50 0.15 1 Source 2 Source 3 Source 4 Gate 5 Drain 6 Drain 7 Drain 8 Drain ■ Absolute Maximum Ratings (TA = 25℃,unless otherwise specified.) Drain-Source Voltage Gate-Source Voltage Parameter Continuous Drain Current (Note 2), VGS = 10V Steady State t<10s TA=25℃ TA=70℃ TA=25℃ TA=70℃ Continuous Drain Current (Note 2), VGS = 4.5V Steady State t<10s TA=25℃ TA=70℃ TA=25℃ TA=70℃ Pulsed Drain Current (10μs pulse, duty cycle = 1%) Maximum Continuous Body Diode Forward Current (Note 2) Avalanche Current (Note 3) L = 0.
