KRF7504 Datasheet | Kexin Semiconductor

Features Generation V Technology Ultra Low On-Resistance Dual P-Channel MOSFET Very Small SOIC Package Low Profile (<1.1mm) Available in Tape & Reel Fast Switching ICIC Absolute Maximum Ratings Ta = 25 Parameter Symbol Continuous Drain Current, VGS @ -4.5V @ TA = 25 Continuous Drain Current, VGS @ -4.5V @ TA = 70 Pulsed Drain Current - 1 Power Dissipation - 2 @TA= 25 Linear Derating Factor Gate-to-Source Voltage Peak Diode Recovery dv/dt - 3 dv/dt Junction and Storage Temperature Range TJ, TSTG Maximum Junction-to-Ambient - 2 R JA - 1 Repetitive rating; pulse width limited by max. junction temperature. - 2 Surface mounted on FR-4 board, t 10sec - 3 ISD -1.2A, di/dt 100A/ s, VDD V(BR)DSS,TJ 150 Rating -1.7 -1.4 -9.6 1.25 10 12 -5.0 -55 to + 150 100 Unit W m W/ V V/ns /W .kexin..cn 1 SMD...
