KRF7750
KRF7750 is Power MOSFET manufactured by Kexin Semiconductor.
Features
Ultra Low On-Resistance Dual P-Channel MOSFET Very Small SOIC Package Low Profile ( 1.1mm) Available in Tape & Reel
TSSOP-8
Unit: mm
1,5,8: Drain 2,3,6,7: Source
4: Gate
Absolute Maximum Ratings Ta = 25
Parameter
Symbol
Drain- Source Voltage
Continuous Drain Current, VGS @ -4.5V @ TC = 25
Continuous Drain Current, VGS @ -4.5V @ TC = 70
Pulsed Drain Current
- 1
Power Dissipation
- 2
@TC= 25
Power Dissipation
- 2
@TC = 70
Linear Derating Factor
Gate-to-Source Voltage
Junction and Storage Temperature Range
TJ, TSTG
Maximum Junction-to-Ambient
- 2
R JA
- 1 Repetitive rating; pulse width limited by max. junction temperature.
- 2 When mounted on 1 inch square copper board, t 10 sec
Rating -20 4.7 3.8 38 1.0 0.64
0.008 12
-55 to + 150 125
Unit...
