MX35UF2GE4AD
FEATURES
- 1Gb, 2Gb, 4Gb Serial Flash
- Bus: x4 1Gb/2Gb: page size: (2048+64) byte, block size:
(128K+4K) byte Note1 4Gb: page size: (4096+128) byte, block size:
(256K+8K) byte Note1
- Fast Read Access
- Supports Random data read out by x1 x2 & x4 modes, (1-1-1,1-1-2, 1-1-4, 1-2-2, 1-4-4)Note 2
- Latency of array to register: 80us for 1Gb/2Gb,
120us for 4Gb
- Frequency: 133MHz Note3
- Continuous read supported
- Page Program Operation
- Page program time: 360us(typ.) for 1Gb/2Gb,
400us(typ.) for 4Gb
- Block Erase Operation
- Block erase time: 4ms(typ.)
- Single Voltage Operation:
- VCC: 1.7 to 1.95V
- BP bits for block group protection
MX35UF1GE4AD MX35UF2GE4AD MX35UF4GE4AD 1.8V, 1Gb/2Gb/4Gb Serial NAND Flash Memory
- Unique ID Read with PUF type code structure
- Low Power Dissipation
- Max 40m A
Active current (Read/Program/Erase)
- Standby Mode
- 110u A (Max) standby current
- High Reliability
- Special Read for data recovery :
Enabled by Set...
