2SD1664
Features
- Halogen free available upon request by adding suffix "-HF"
- plements to 2SB1132
- Low collector-to-emitter saturation voltage.
- Fast switching speed.
- Epoxy meets UL 94 V-0 flammability rating
- Moisture Sensitivity Level 1
- Lead Free Finish/Rohs pliant ("P"Suffix designates
Ro HS pliant. See ordering information)
Maximum Ratings
Symbol VCEO VCBO VEBO
Rating Collector-Emitter Voltage Collector-Base Voltage Emitter-Base Voltage
Rating
Unit
Collector Current
PC TJ TSTG
Collector dissipation Junction Temperature Storage Temperature
500 m W
-55 to +150
-55 to +150
Electrical Characteristics @ 25OC Unless Otherwise Specified
Symbol
Parameter
OFF CHARACTERISTICS
Min Typ Max Units
V(BR)CBO Collector-Base Breakdown Voltage
40 --- --- Vdc
(IC=50µAdc, IE=0)
V(BR)CEO Collector-Emitter Breakdown Voltage 32
---
---
Vdc
(IC=1.0m Adc)
V(BR)EBO Collector-Emitter Breakdown Voltage 5.0...
