MT7976DAN
MT7976DAN is 802.11ax Wi-Fi RF Chip manufactured by MEDIATEK.
FOR jianMgEdiDIngAyToEngK@CtOwsNz.FIcoDmENUTSIEALONLY
MT7976DAN Datasheet
802.11ax Wi-Fi RF Chip
Version: Release date:
1.4 2021/11/15
FOR jianMgEdiDIngAyToEngK@CtOwsNz.FIcoDmENUTSIEALONLY
1 System Overview
Functional Block Diagram
MT7976DAN is an IEEE WiFi 6 MIMO RF chip which contains 2.4 GHz WI-Fi transceiver front-ends and 5 GHz Wi-Fi transceiver front-ends in a DRQFN package. Simplified block diagram and how MT7976DAN is used are shown in Figure 1-1. The top control logics control each subsystem independently. Each subsystem also has dedicated LDOs. A thermal sensor and a low-speed ADC (Analog-to-Digital Converter) are provided to monitor MT7976DAN’s temperature variation....
