Datasheet Summary
Features
- Fast Switching Speed
- Ultra-Small Surface Mount Package
- For General Purpose Switching Applications
- High Conductance
SWITCHING DIODE
SOT-363 top view
Schematic diagram
Marking and pin assignment
Maximum Ratings(Ta=25℃ unless otherwise noted)
Symbol
Parameter
VR VRRM VRWM IFM Io
IFSM PD RθJA TJ , TSTG
Reverse Voltage Working Peak Reverse Voltage DC Blocking Voltage Forward Continuous Current Average Rectified Output Current Non-Repetitive Peak Forward Surge Current @t=8.3ms Power Dissipation Thermal Resistance Junction to Ambient Operating and Storage Temperature Range
Value
75 75 75 300 150 2 200 625 -55~ +150
Unit
V mA mA A mW ℃/W ℃
ELECTRICAL...
