2N2907A - High Speed Switching Transistor

This page provides the datasheet information for the 2N2907A, a member of the 2N2906A High Speed Switching Transistor family.

Datasheet Summary

Description

Collector Emitter Voltage Collector Base Voltage Emitter Base Voltage Collector Current Continuous Power Dissipation @ Ta = 25ºC Derate above 25ºC Power Dissipation @ Tc = 25ºC Derate Above 25ºC Operating and Storage Junction Temperature Range Symbol Vceo Vcbo Vebo Ic Pd Pd Tj, Tstg Value 60 5 6

Features

  •   PNP silicon planar switching transistors.
  •   Fast switching devices exhibiting short turn-off and low saturation voltage characteristics.
  •   Switching and linear.

📥 Download Datasheet

Datasheet preview – 2N2907A

Datasheet Details

Part number 2N2907A
Manufacturer Multicomp
File Size 282.71 KB
Description High Speed Switching Transistor
Datasheet download datasheet 2N2907A Datasheet
Additional preview pages of the 2N2907A datasheet.

📁 Similar Datasheet

  • 2N2907A - PNP switching transistors (NXP)
  • 2N2907A - Radiation Hardened PNP Transistors (VPT)
  • 2N2907A - Transistors (Diotec)
  • 2N2907A - SMALL SIGNAL PNP TRANSISTORS (ST Microelectronics)
  • 2N2907A - PNP TRANSISTOR (Microsemi Corporation)
  • 2N2907A - HIGH SPEED MEDIUM POWER PNP TRANSISTOR (Seme LAB)
  • 2N2907A - PNP Silicon Annular Hermetic Transistors (Motorola)
  • 2N2907A - General Purpose Amplifier Transistors (Comset Semiconductor)
  • 2N2907A - PNP Switching Transistors (MCC)
  • 2N2907A - Small Signal Switching Transistor (ON Semiconductor)
Other Datasheets by Multicomp
  • 2N2905A - General Purpose Transistor
  • 2N2906A - High Speed Switching Transistor
  • 2N2102 - Transistor
  • 2N2218A - Bipolar Transistor
  • 2N2222 - Low Power Bipolar Transistors
  • 2N2369 - High Speed Switching Transistors
  • 2N2369A - High Speed Switching Transistors
  • 2N2484 - NPN Bipolar Transistor

Full PDF Text Transcription

Click to expand full text
High Speed Switching Transistor Features: •  PNP silicon planar switching transistors •  Fast switching devices exhibiting short turn-off and low saturation voltage characteristics •  Switching and linear application DC and VHF amplifier applications Absolute Maximum Ratings Description Collector Emitter Voltage Collector Base Voltage Emitter Base Voltage Collector Current Continuous Power Dissipation @ Ta = 25ºC Derate above 25ºC Power Dissipation @ Tc = 25ºC Derate Above 25ºC Operating and Storage Junction Temperature Range Symbol Vceo Vcbo Vebo Ic Pd Pd Tj, Tstg Value 60 5 600 400 2.28 1.8 10.3 -55 to +175 Unit V mA mW mW/ ºC W mW/ ºC ºC Pin Configuration 1. Emitter 2. Base 3.
