NSPGD1
NSPGD1 is Intergrated Gauge Pressure Sensor manufactured by NOVOSENSE.
NSPGD1 Series
Integrated Gauge Pressure Sensor
Datasheet (EN) 3.0
Product Overview
NSPGD1 series are calibrated gauge pressure sensor which bines state-of-art MEMS sensor technology and CMOS mix-signal processing technology to produce an amplified, fully conditioned, multi-order pressure and temperature pensated sensor in a Double In-line Package (DIP) with tube port. NSPGD1 series pressure sensor is target for household electric appliances and the small kitchen and bathroom home-appliances. bining the pressure sensor with a signal conditioning ASIC in a single package simplifies the use of advanced silicon micromachined pressure sensors. The pressure sensor can be mounted directly to a standard printed circuit board and an amplified, high-level, calibrated pressure signal can be acquired from the digital interface or analog/frequency output. This eliminates the need for additional circuitry, such as a pensation network or micro-controller containing a custom correction algorithm. NSPGD1 series are designed for operating pressure ranges of -10k Pa ~ 10k Pa Gauge, very suitable for household electronics such as washing machine and dishwasher.
Applications
- Washing machine
- Dishwasher, water purifier
- Air bed, massage chair
- Smart sphygmomanometer, oxygen generator
- Industrial control
- Io T pressure detection
Device Information
Part Number NSPGD1
Package DIP8
Body Size 10.4mm- 10.4mm
Outline
Key Features
- Custom range -10k Pa~10k Pa
- High accuracy
Total error band initially better than ±1%F.S. Full life accuracy better than ±2.5%F.S.
- Temperature range 0~70°C
- Ratio-metric/Absolute analog output
- 24bit I2C output
- Frequency output
- Front side of the chip enters the gas, not easing to block
- Waterproof and moisture-proof treatment inside
- Ro HS & REACH pliance
