Datasheet Summary
Monolithic Dual Switching Diode
Features
- These Devices are Pb- Free, Halogen Free/BFR Free and are RoHS pliant
MAXIMUM RATINGS (EACH DIODE)
Rating
Symbol Value
Unit
Reverse Voltage Forward Current Peak Forward Surge Current
Vdc
200 mAdc
IFM(surge)
500 mAdc
THERMAL CHARACTERISTICS
Characteristic
Symbol
Max
Unit
Total Device Dissipation FR- 5 Board
(Note 1), TA = 25°C
225 mW
Derate above 25°C
1.8 mW/°C
Thermal Resistance, Junction- to- Ambient
Total Device Dissipation Alumina Substrate, (Note 2) TA = 25°C Derate above 25°C
RqJA PD
°C/W
300 mW
2.4 mW/°C
Thermal Resistance, Junction- to- Ambient...
