BCW68GL - PNP Transistor

Key Features

  • NSV Prefix for Automotive and Other.

📥 Download Datasheet

Datasheet Details

Part number BCW68GL
Manufacturer onsemi
File Size 146.67 KB
Description PNP Transistor
Datasheet download datasheet BCW68GL Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
BCW68GLT1 Transistor Motorola Inc
BCW68GLT1 PNP Transistor Leshan Radio Company
BCW68G PNP Amplifier GME
BCW68G PNP Transistor Infineon
BCW68G PNP Amplifier Fairchild Semiconductor

Other Datasheets by onsemi

Part Number Description
BCW68G PNP Amplifier
BCW66GLT1G General Purpose Transistor
BCW69LT1 General Purpose Transistors
BCW30LT1 General Purpose Transistors(PNP Silicon)
BCW30LT1G General Purpose Transistors

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
BCW68GL General Purpose Transistor PNP Silicon Features • NSV Prefix for Automotive and Other Applications Requiring Unique Site and Control Change Requirements; AEC−Q101 Qualified and PPAP Capable • These Devices are Pb−Free, Halogen Free/BFR Free and are RoHS Compliant www.onsemi.com COLLECTOR 3 1 BASE MAXIMUM RATINGS Rating Symbol Value Unit Collector−Emitter Voltage VCEO −45 Vdc Collector−Base Voltage VCBO −60 Vdc Emitter−Base Voltage VEBO −5.0 Vdc Collector Current − Continuous IC −800 mAdc Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality should not be assumed, damage may occur and reliability may be affected.
