1SS388
1SS388 is Silicon Epitaxial Schottky Barrier Type Diode manufactured by PanJit Semiconductor.
SILICON EPITAXIAL SCHOTTKY BARRIER TYPE
Features
- Low forward voltage : VF(3)=0.54V(typ.)
- Low reverse current : IR=5μA(typ.)
- Lead free in pliance with EU RoHS 2011/65/EU directive
- Green molding pound as per IEC61249 Std. . (Halogen Free)
APPLICATIONS
- Case : SOD-523 plastic
- Terminals : Solderable per MIL-STD-750,Method 2026
- Approx Weight : 0.00005 ounces, 0.0014 grams
- Marking : 38
Cathode
Anode
0.034(0.85) 0.029(0.75)
0.050(1.25) 0.045(1.15)
0.014(0.35) 0.009(0.25)
0.026(0.65) 0.021(0.55)
0.067(1.70) 0.059(1.50)
0.006(0.15) 0.002(0.05)
0.20 MIN.
MAXIMUM RATINGS (TA=25oC)
Characteristic Maximum (peak) reverse voltage Reverse voltage Maximum (peak)...
