MMBT3906 - PNP Small Signal Transistor

Key Features

  • - Epitaxial planar die construction - Surface device type mounting - Moisture sensitivity level 1 - Matte Tin (Sn) lead finish with Nickel (Ni) underplate - Pb free version and RoHS compliant - Packing code with suffix "G" means green compound (halogen-free) SOT-23.

📥 Download Datasheet

📁 Similar Datasheet

Part Number Description Manufacturer
MMBT3906 40V PNP SMALL SIGNAL TRANSISTOR Diodes
MMBT3906 PNP Transistor CITC
MMBT3906 PNP Transistor GOOD-ARK
MMBT3906 PNP General-Purpose Amplifier ON Semiconductor
MMBT3906 SMALL SIGNAL PNP TRANSISTOR STMicroelectronics

Other Datasheets by Taiwan Semiconductor

Part Number Description
MMBT3906L PNP Small Signal Transistor
MMBT3904 NPN Transistor
MMBT2222A NPN Transistor
MMBT2907A PNP Transistor
MMBTA05 NPN Small Signal Transistor

Full PDF Text Transcription (Reference)

The following content is an automatically extracted verbatim text from the original manufacturer datasheet and is provided for reference purposes only.

View original datasheet text
Small Signal Product MMBT3906 Taiwan Semiconductor 350mW, PNP Small Signal Transistor FEATURES - Epitaxial planar die construction - Surface device type mounting - Moisture sensitivity level 1 - Matte Tin (Sn) lead finish with Nickel (Ni) underplate - Pb free version and RoHS compliant - Packing code with suffix "G" means green compound (halogen-free) SOT-23 MECHANICAL DATA - Case: SOT- 23, molded plastic - Terminal: Matte tin plated, lead free, solderable per MIL-STD-202, Method 208 guaranteed - High temperature soldering guaranteed: 260oC/10s - Weight: 0.
