Datasheet Summary
HBS-patible Driver and Receiver Monolithic IC
Features
- Built in dynamic impedance matching function
- Built in decoding error correction function
- Built in decoding signal correction function
- Built in hardware codec
- Enhanced anti-interference ability
- Support multiple network topologies
- Support adjusting load balancing time
- Simple circuit design
- High reliability
- munication speed adaptation from
9.6kbps to 57.6kbps
- Operating temperature -40℃~125℃
- Available in QFN3- 3-16 package
Applications
- Central Air Conditioner
- HVAC
- Smart Home
- Remote Monitoring and Sensing
General Description The XL1191 conforms to the HBS(Home Bus) specification,...
