DTA143TUA
DTA143TUA is PNP Digital Transistors manufactured by Yangjie Electronic.
DTA143TUA PNP Digital Transistors (Built-in Resistors)
RoHS
PLIANT
SOT-323
Features
- Moisture sensitivity level 1
- General switching and amplification
- Surface mount package ideally suited for automatic insertion
Application
- Signal amplification
- Switching circuit
Mechanical data
- Package： SOT-323
- Terminals：Tin plated leads, solderable per J-STD-002 and JESD22-B102
- Maximum Ratings (Ta=25℃ Unless otherwise specified)
Item
Symbol
Unit
Conditions
Device marking code
Collector-base voltage
VCBO
IC=-50uA
Collector-emitter voltage Emitter-base voltage Collector current
VCEO VEBO
IC=-1mA
IE=-50uA mA
Power dissipation
PD mW
Junction...
