AZ6961 - 10 AMP SUBMINIATURE

Features

High sensitivity, 120 mW pickup Dielectric strength 5000 Vrms Isolation spacing greater than 8 mm 10 Amp switching capability Epoxy sealed version available Reinforced insulation, EN 60730-1 (VDE 0631, part 1) UL, CUR file E43203 VDE file 131637.

ZETTLER Electronics

Datasheet Details

Part number	AZ6961
Manufacturer	ZETTLER Electronics
File Size	86.38 KB
Description	10 AMP SUBMINIATURE
Datasheet	AZ6961 Datasheet
Additional preview pages of the AZ6961 datasheet.

📁 Similar Datasheet

AZ6963 - 10 AMP SUBMINIATURE POWER RELAY (Zettler)
AZ6951 - SENSITIVE SUBMINIATURE RELAY (Zettler)
AZ6975 - MINIATURE POWER RELAY (American Zettler)
AZ6991 - SENSITIVE SUBMINIATURE RELAY (Zettler)
AZ6208B - REVERSIBLE MOTOR DRIVER (BCD Semiconductor)
AZ680K - Ceramic Composite Resistors (OHMITE)
AZ681K - Ceramic Composite Resistors (OHMITE)

Other Datasheets by ZETTLER Electronics

AZ696 - SUBMINIATURE POWER RELAY
AZ6962 - SUBMINIATURE POWER RELAY
AZ692 - (AZ692 / AZ693) MINIATURE POWER RELAY
AZ693 - (AZ692 / AZ693) MINIATURE POWER RELAY
AZ695 - SENSITIVE SUBMINIATURE RELAY
AZ697 - MINIATURE POWER RELAY
AZ699 - SENSITIVE SUBMINIATURE RELAY
AZ683 - MINIATURE POWER RELAY

Full PDF Text Transcription

Click to expand full text

AZ6961 10 AMP SUBMINIATURE POWER RELAY FEATURES • • • • • • • • High sensitivity, 120 mW pickup Dielectric strength 5000 Vrms Isolation spacing greater than 8 mm 10 Amp switching capability Epoxy sealed version available Reinforced insulation, EN 60730-1 (VDE 0631, part 1) UL, CUR file E43203 VDE file 131637 CONTACTS Arrangement Ratings SPDT (1 Form C) SPST (1 Form A) Resistive load: Max. switched power: 240 W or 2500 VA Max. switched current: 10 A Max. switched voltage: 240* VDC or 440 VAC * Note: If switching voltage is greater than 30 VDC, GENERAL DATA Life Expectancy Mechanical Electrical Operate Time (typical) Release Time (typical) Minimum operations 1 x 107 1 x 105 at 8 A 250 VAC res.
