AZ932
Overview
- High performance
- Low seated height
- Flux tight and sealed versions available
- Class F insulation (155°C) system available
- Class B Insulation (130°C) standard
- UL, CUR file E43203 CONTACTS Arrangement Ratings Rated Load UL/CUR Material Resistance SPST - N.O. (1 Form A) SPST - N.C. (1 Form B) SPDT (1 Form C) Form A, B and C Max. switched power: 210W or 1800VA Max. switched current: 15A (AC), 7A (DC ) Max. switched voltage: 30VDC or 277VAC 1 Form A 15A at 120VAC 100,000 cycles TV - 5 120VAC 1 Form B NC (Class F Only) 8.3A at 120VAC, 1000VA, 90°C Ballast 3.6A at 277VAC, 1000VA, 90°C Ballast 8A at 120VAC, 10k cycles, 80°C Electronic Ballast 3A at 277VAC, 10k cycles, 80°C Electronic Ballast 1 Form B NC (Class B Only) 15A at 120VAC, 1800VA, 25°C Ballast 6.5A at 277VAC, 1800VA, 25°C Ballast 1 Form C 10A at 120VAC 100,000 cycles N.O. 10A at 120VAC 50,000 cycles N.C. Silver tin oxide (gold plating available) < 100 milliohms initially (6V, 1A voltage drop method) COIL Power At Pickup Voltage Max Continuous Dissipation Temperature Rise (at nominal coil voltage) Temperature 203mW 0.6W at 20°C (68°F) 27°C (49°F) Max. 130°C (266°F)
