AZ850
FEATURES
- pact size: Height: 0.197“ (5 mm); Length: 0.551“ (14 mm); Width: 0.354“ (9 mm)
- DPDT (2 Form C) contact arrangements
- Monostable non-latching and bistable latching types available
- Single and dual coil latching versions
- High sensitivity coil
- 79 m W pickup
- Meets FCC Part 68.302 1500 V lightning surge
- DIP terminal layout, fits 10 pin IC socket
- Epoxy sealed for automatic wave soldering and cleaning
- Gold clad contacts
- Ro HS pliant
- UL, CUR file E43203
CONTACTS
Arrangement
Ratings (max.) switched power switched current carry current switched voltage
Rated Loads UL, CUR
DPDT (2 Form C) Bifurcated crossbar contacts
(resistive load) 30 W or 62.5 VA 1A 2A 220 VDC- or 250 VAC
- Note: If switching voltage is greater than 30 VDC, special precautions must be taken. Please contact the factory.
1 A at 30 VDC, resistive 0.5 A at 125 VAC, resistive
Contact materials Ag Pd
- silver palladium, gold clad
Minimum switching voltage
10 m V current
10 µA
Initial resistance <...
