AZ852
FEATURES
- Conforms to IEC60950/UL1950/EN60950 spacing and high breakdown voltage Clearance: 1.0 mm (between coil and contacts) Creepage: 1.6 mm (between coil and contacts) Basic Insulation: 150 V Working Voltage, Pollution Degree 2
- Monostable and bistable (latching) coil versions available
- High dielectric and surge voltage:
2.5 KV surge (per Bellcore TA- NWT- 001089) 1.5 KV surge (per FCC Part 68) 1,000 Vrms, open contacts
- Low power consumption: 64 m W pickup
- Stable contact resistance for low level signal switching
- Epoxy sealed for automatic wave soldering and cleaning
- UL file E43203; CSA file 212940
- All plastics meet UL94 V- 0, 30 min. oxygen index
CONTACTS
Arrangement Ratings
Rated Load UL/CSA
Material Resistance
DPDT (2 Form C) Bifurcated crossbar contacts
Resistive load: Max. switched power: 60 W or 62.5 VA Max. switched current: 2.0 A Max. switched voltage: 220 VDC or 250 VAC
0.5 A at 125 VAC 2.0 A at 30 VDC 0.3 A at 110 VDC
Silver alloy; gold clad
< 75 milliohms...
