LMK6H Overview
Key Specifications
Pins: 6
Height: 0 m
Length: 2.5 mm
Width: 2 mm
Key Features
- ±25ppm total frequency stability inclusive of 10 years aging and all other factors
- Smallest industry standard DLE and DLF packages
- Support extended industrial temperature grade: – LMK6P/LMK6D/LMK6H: –40°C to 85°C – LMK6C: –40°C to 105°C
- Integrated LDO for robust supply noise immunity: – –72dBc PSRR at 500kHz ripple
- Start-up time: < 5ms
- Device can support any frequency between 1MHz to 400MHz. Contact TI representative for any frequency and samples needed
