PE25204 Datasheet 6a Charge Pump / Capacitor Divider

Manufacturer: pSemi

Overview: PE25204 Document Category: Product Specification 48VIN, Divide-by-4, 6A Charge Pump, Capacitor Divider.

Datasheet Details

Part number	PE25204
Manufacturer	pSemi
File Size	4.03 MB
Description	6A Charge Pump / Capacitor Divider
Datasheet	PE25204-pSemi.pdf

General Description

The PE25204 is an ultra-high efficiency charge pump solution that divides down an input voltage by 4 and delivers up to 72W output at up to 96.8% peak efficiency.

The PE25204 can also be used in parallel to increase output power.

The PE25204 supports an input voltage range of 18V to 60V in divide-by-4 operation.

Key Features

Proprietary architecture enables industry-leading efficiency in an ultra-compact solution footprint and profile.
96.8% peak efficiency and up to 72W per part.
Parts can be operated in parallel for higher output power.
Input voltage range of 18V to 60V supports 48V bus systems and 24V industrial supplies.
Fixed divide-by-4 from input voltage to output voltage.
Fully protected with input under-voltage, output short circuit detection, and thermal shutdown fault detect.
