Description
The PTRA093818NF is a 415-watt LDMOS FET intended for use in multi-standard cellular power amplifier applications in the 925 to 960 MHz frequency band.
Features
- include input matching, high gain and thermally-enhanced package with earless flanges. Manufactured with Wolfspeed’s advanced LDMOS process, this device provides excellent thermal performance and superior reliability. Package Types: PG-HBSOF-6-2
Peak/Average Ratio, Gain (dB) Efficiency (%)
Single-carrier WCDMA Drive-up VDD = 48 V, IDQ(MAIN) = 200 mA, VGS(PEAK) = 2.0 V, ƒ = 960 MHz,
3GPP WCDMA signal, PAR = 10 dB,
3.84 MHz BW
32
80
28
Efficiency
60
24
40
20
20
16
0
12
Gain
-20
8.
PTRA093818NF Datasheet
